Symbologies

Contents

Symbologies#

All Symbologies#

../../media/3030900.png

Disable#

../../media/3030901.png

Enable#

1D Symbologies#

../../media/3030110.png

Disable#

../../media/3030111.png

Enable#

2D Symbologies#

../../media/3030500.png

Disable#

../../media/3030501.png

Enable#

1D Reverse Symbologies#

Note

  • Regular barcode: Dark image on a bright background.

  • Inverse barcode: Bright image on a dark background.

../../media/3030910.png

* Disable#

../../media/3030911.png

Enable#

Block Barcodes With URLs#

Block scanning of URL QR codes starting with http://, https://

Disable#

../../media/3030EA0.png

* Disable#

Enable#

../../media/3030EA1.png

Enable#

UPC-A#

Enable/Disable#

../../media/1000011.png

Disable#

../../media/1000010.png

* Enable#

Transmit Preamble Character#

Preamble characters (country code and system characters) can be transmitted as part of the UPC-A symbology. Select one of the following options to set and transmit a UPC-A preamble to the host: Transmit system characters only, Transmit system characters and country code (“0” for the United States), or Transmit no preamble.

../../media/2030100.png

No System Character#

../../media/2030101.png

* System Character#

../../media/2030102.png

System Character & Country Code#

Transmit Check Character#

../../media/1020020.png

Disable#

../../media/1020021.png

* Enable#

2-Digit Add-On Code#

../../media/3030400.png

* Disable#

../../media/3030401.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

5-Digit Add-On Code#

../../media/3030410.png

* Disable#

../../media/3030411.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

Only decode barcodes with Add-On Code#

When Enable is selected, the scanner will only read barcodes that contain add-on codes.

../../media/3030420.png

* Disable#

../../media/3030421.png

Enable#

UPC-E#

Enable/Disable#

../../media/1000020.png

Disable#

../../media/1000021.png

* Enable#

Transmit Preamble Character#

Preamble characters (country code and system characters) can be transmitted as part of the UPC-A symbology. Select one of the following options to set and transmit a UPC-A preamble to the host: Transmit system characters only, Transmit system characters and country code (“0” for the United States), or Transmit no preamble.

../../media/2030000.png

No System Character#

../../media/2030001.png

* System Character#

../../media/2030002.png

System Character & Country Code#

Transmit Check Character#

../../media/1020030.png

Disable#

../../media/1020031.png

* Enable#

Convert UPC-E to UPC-A#

../../media/1020000.png

* Disable#

../../media/1020001.png

Enable#

When Enable is selected,Converts UPC-E decoded data to UPC-A format. After conversion, the data follows the UPC-A format and is affected by UPC-A programming selections (e.g., preamble, check digit).

2-Digit Add-On Code#

../../media/30303D0.png

* Disable#

../../media/30303D1.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

5-Digit Add-On Code#

../../media/30303E0.png

* Disable#

../../media/30303E1.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

Only decode barcodes with Add-On Code#

When Enable is selected, the scanner will only read barcodes that contain add-on codes.

../../media/30303F0.png

* Disable#

../../media/30303F1.png

Enable#

UPC-E1 Switch#

../../media/3030150.png

* Disable#

../../media/3030151.png

Enable#

EAN-8#

Enable/Disable#

../../media/1000040.png

Disable#

../../media/1000041.png

* Enable#

EAN-8 Extension#

When Enable is selected, the scanner adds five leading zeros to the decoded EAN-8 barcode to extend to 13 digits.

../../media/1020010.png

* Disable#

../../media/1020011.png

Enable#

2-Digit Add-On Code#

../../media/3030370.png

* Disable#

../../media/3030371.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

5-Digit Add-On Code#

../../media/3030380.png

* Disable#

../../media/3030381.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

Only decode barcodes with Add-On Code#

When Enable is selected, the scanner will only read barcodes that contain add-on codes.

../../media/3030390.png

* Disable#

../../media/3030391.png

Enable#

Transmit Check Character#

../../media/3030800.png

Disable#

../../media/3030801.png

* Enable#

EAN-13#

Enable/Disable#

../../media/1000030.png

Disable#

../../media/1000031.png

* Enable#

2-Digit Add-On Code#

../../media/30303A0.png

* Disable#

../../media/30303A1.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

5-Digit Add-On Code#

../../media/30303B0.png

* Disable#

../../media/30303B1.png

Enable#

Note

  • Disable:When the scanner scans a barcode with an additional code, it decodes the barcode and ignores the additional code. The scanner can also decode barcodes without the additional code.

  • Enable:Scanner decodes a mix of barcodes with and without add-on codes.

Only decode barcodes with Add-On Code#

When Enable is selected, the scanner will only read barcodes that contain add-on codes.

../../media/30303C0.png

* Disable#

../../media/30303C1.png

Enable#

Transmit Check Character#

../../media/3030160.png

Disable#

../../media/3030161.png

* Enable#

Bookland EAN(ISBN)#

Enable/Disable#

../../media/1000230.png

* Disable#

../../media/1000231.png

Enable#

Code 128#

Enable/Disable#

../../media/1000100.png

Disable#

../../media/1000101.png

* Enable#

Transmit Check Character#

../../media/3030350.png

* Disable#

../../media/3030351.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3118485F50000005.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0118485F50000005.png

Any Length#

GS1-128 (UCC/EAN-128)#

Enable/Disable#

../../media/1040330.png

Disable#

../../media/1040331.png

* Enable#

Transmit Check Character#

../../media/3030360.png

* Disable#

../../media/3030361.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3118687F50000007.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0118687F50000007.png

Any Length#

ISBT 128#

Enable/Disable#

../../media/1000330.png

Disable#

../../media/1000331.png

* Enable#

Code 39#

Enable/Disable#

../../media/1000000.png

Disable#

../../media/1000001.png

* Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010001013700000.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010001013700000.png

Any Length#

Check Digit Verification#

When this feature is enabled, the scanner checks the integrity of all Code 39 symbologies to verify that the data complies with the specified check digit algorithm. Only Code 39 symbologies that contain a modulo 43 check digit can be decoded.

../../media/1020040.png

* Disable#

../../media/1020041.png

Enable#

Transmit Check Character#

../../media/1020240.png

* Disable#

../../media/1020241.png

Enable#

Code 39 Full ASCII#

../../media/1020110.png

* Disable#

../../media/1020111.png

Enable#

Transmit Start And End Characters#

../../media/3030300.png

* Disable#

../../media/3030301.png

Enable#

Code 32#

Convert Code 39 To Code 32 (Italian Pharmaceutical Code)#

Code 32 is a variation of Code 39 used by the Italian pharmaceutical industry. Scan the appropriate bar code below to enable or disable the conversion of Code 39 to Code 32.

../../media/1020300.png

* Disable#

../../media/1020301.png

Enable#

Code 32 Prefix#

Enabling this parameter adds the prefix character “A” to all Code 32 codes. Before enabling this parameter, you must convert Code 39 to Code 32 (Italian Pharmaceutical Code)

../../media/1020320.png

* Disable#

../../media/1020321.png

Enable#

Code 32 Checksum Verification#

../../media/3030190.png

* Disable#

../../media/3030191.png

Enable#

Transmit Code 32 Check Digit#

../../media/30301A0.png

* Transmission Check Digit#

../../media/30301A1.png

Transmission Start Character, End Character, Check Bit#

Code 93#

Enable/Disable#

../../media/1000110.png

Disable#

../../media/1000111.png

* Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010A0B023700011.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010A0B023700011.png

Any Length#

Code 11#

Enable/Disable#

../../media/1000120.png

* Disable#

../../media/1000121.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010C0D013700012.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010C0D013700012.png

Any Length#

Check Digit Verification#

This feature allows the scanner to check the integrity of all Code 11 symbologies to verify that the data conforms to a specified check digit algorithm. This selects the check digit mechanism for the decoded Code 11 barcode. Options include checking one check digit, checking two check digits, or disabling the feature.

../../media/2051200.png

* Disable#

../../media/2051201.png

One Check Digit#

../../media/2051202.png

Two Check Digits#

Transmit Check Character#

../../media/1020140.png

* Disable#

../../media/1020141.png

Enable#

Interleaved 2 of 5/ITF#

Enable/Disable#

../../media/1000060.png

Disable#

../../media/1000061.png

* Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010809024400006.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010809024400006.png

Any Length#

Check Digit Verification#

When enabled, this parameter checks the integrity of the I 2 of 5 symbology to ensure that it complies with the specified algorithm, including USS (Uniform Symbol Specification) or OPCC (Optical Product Code Committee).

../../media/2051E00.png

* Disable#

../../media/2051E01.png

Enable#

Transmit Check Character#

../../media/1020210.png

* Disable#

../../media/1020211.png

Enable#

Discrete 2 of 5/Industrial 2 of 5/IND25#

Enable/Disable#

../../media/1000050.png

* Disable#

../../media/1000051.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010607023700005.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010607023700005.png

Any Length#

Check Digit Verification#

../../media/3030480.png

* Disable#

../../media/3030481.png

Enable#

Transmit Check Character#

../../media/3030490.png

* Disable#

../../media/3030491.png

Enable#

Matrix 25#

Enable/Disable#

../../media/3030200.png

* Disable#

../../media/3030201.png

Enable#

Check Digit Verification#

../../media/3030210.png

* Disable#

../../media/3030211.png

Enable#

Transmit Check Character#

../../media/3030220.png

* Disable#

../../media/3030221.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3118081F50000001.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0118081F50000001.png

Any Length#

Standdard 25/IATA 25#

Enable/Disable#

../../media/3030230.png

* Disable#

../../media/3030231.png

Enable#

Check Digit Verification#

../../media/3030240.png

* Disable#

../../media/3030241.png

Enable#

Transmit Check Character#

../../media/3030250.png

* Disable#

../../media/3030251.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3118283F50000003.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0118283F50000003.png

Any Length#

Codabar#

Enable/Disable#

../../media/1000070.png

* Disable#

../../media/1000071.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010203023700007.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010203023700007.png

Any Length#

Check Digit Verification#

../../media/30304C0.png

* Disable#

../../media/30304C1.png

Enable#

Transmit Check Character#

../../media/30304D0.png

* Disable#

../../media/30304D1.png

Enable#

NOTIS Editing#

../../media/1020060.png

* Disable#

../../media/1020061.png

Enable#

Start And End Character Formats#

Note

  • ABCD/ABCD The start and end characters can be one of the following four characters: “A”, “B”, “C”, “D”;

  • ABCD/TN*E The start character can be one of the following four characters: “A”, “B”, “C”, “D”; the end character can be one of the following four characters: “T”, “N”, “*”, “E”.

../../media/3030310.png

* ABCD/ABCD#

../../media/3030311.png

ABCD/TN*E#

Start And End Character Case#

../../media/3030320.png

* Uppercase Letter#

../../media/3030321.png

Lowercase Letters#

MSI/MSI Plessey#

Enable/Disable#

../../media/1000140.png

* Disable#

../../media/1000141.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3010F10013700014.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0010F10013700014.png

Any Length#

Check Digit Verification#

../../media/1020120.png

* One Check Digit#

../../media/1020121.png

Two Check Digits#

Transmit Check Character#

../../media/1020130.png

* Disable#

../../media/1020131.png

Enable#

Check Digit Algorithm#

When the Two MSI Check Digits option is selected, additional verification is required to ensure integrity. Select one of the following algorithms:

../../media/1020230.png

MOD 10/MOD 11#

../../media/1020231.png

* MOD 10/MOD 10#

GS1 DataBar/RSS#

Enable/Disable#

../../media/1000350.png

* Disable#

../../media/1000351.png

Enable#

RSS AI Character#

../../media/3030260.png

Disable#

../../media/3030261.png

* Enable#

PDF417#

Enable/Disable#

../../media/1000170.png

Disable#

../../media/1000171.png

* Enable#

Regular/Inverse Decode#

Note

  • Regular barcode: Dark image on a bright background.

  • Inverse barcode: Bright image on a dark background.

../../media/3030610.png

* Decode Regular Barcodes Only#

../../media/3030611.png

Decode Inverse Barcodes Only#

../../media/3030612.png

Decode Both#

QR Code#

Enable/Disable#

../../media/1003250.png

Disable#

../../media/1003251.png

* Enable#

ECI Output#

../../media/3030660.png

* Disable#

../../media/3030661.png

Enable#

Regular/Inverse Decode#

Note

  • Regular barcode: Dark image on a bright background.

  • Inverse barcode: Bright image on a dark background.

../../media/3030670.png

* Decode Regular Barcodes Only#

../../media/3030671.png

Decode Inverse Barcodes Only#

../../media/3030672.png

Decode Both#

Data Matrix(DM)#

Enable/Disable#

../../media/1003240.png

Disable#

../../media/1003241.png

* Enable#

ECI Output#

../../media/30306C0.png

* Disable#

../../media/30306C1.png

Enable#

Regular/Inverse Decode#

Note

  • Regular barcode: Dark bars on a bright background.

  • Inverse barcode: Bright bars on a dark background.

../../media/30306B0.png

* Decode Regular Barcodes Only#

../../media/30306B1.png

Decode Inverse Barcodes Only#

../../media/30306B2.png

Decode Both#

Maxi Code#

Enable/Disable#

../../media/1003260.png

* Disable#

../../media/1003261.png

Enable#

Aztec Code#

Enable/Disable#

../../media/1003280.png

* Disable#

../../media/1003281.png

Enable#

Han Xin COde#

Enable/Disable#

../../media/10032F0.png

* Disable#

../../media/10032F1.png

Enable#

Regular/Inverse Decode#

Note

  • Regular barcode: Dark image on a bright background.

  • Inverse barcode: Bright image on a dark background.

../../media/3030710.png

* Decode Regular Barcodes Only#

../../media/3030711.png

Decode Inverse Barcodes Only#

../../media/3030712.png

Decode Both#

ISSN#

Enable/Disable#

Convert to EAN13 when disabled

../../media/3030330.png

* Disable#

../../media/3030331.png

Enable#

NEC-25(COOP25)#

Enable/Disable#

../../media/3030450.png

* Disable#

../../media/3030451.png

Enable#

Enable/Disable#

../../media/3030200.png

* Disable#

../../media/3030201.png

Enable#

Check Digit Verification#

../../media/3030460.png

* Disable#

../../media/3030461.png

Enable#

Transmit Check Character#

../../media/3030470.png

* Disable#

../../media/3030471.png

Enable#

Set Length Range#

The length of a barcode refers to the number of characters (i.e. human-readable characters) contained in the barcode, including the check digit. The length of a barcode can be set to any length, within a specific range.

Note

When setting lengths, single digit numbers must always be preceded by a leading zero.

Length Of Specific Range#

Allows reading of barcodes with a specific length. First scan the barcode with a length within a specific range, then scan the 4-digit setting code in the appendix to set the corresponding two lengths L1 and L2. L1 and L2 each occupy a two-digit setting code, and any digits less than 2 are padded with 0,setting range: 01-99.

  • When L1 < L2, L1 is the minimum length and L2 is the maximum length.

  • When L1 > L2, L1 is the maximum length and L2 is the minimum length.

  • When L1 = L2, only the fixed length (L1/L2) is read

Tip

  • Only 4-8 characters are allowed to be read, so scan the digital setting code “0” “4” “0” “8” or “0” “8” “0” “4”

  • To read only 12 characters, scan the digital setting code “1” “2” “1” “2”

../../media/F3118889F50000009.png

Length Of Specific Range#

Any Length#

To read barcodes of any length, just scan any length without scanning the digital setting code. Default: 0-99

../../media/F0118889F50000009.png

Any Length#

COMPOSITE#

Enable/Disable#

../../media/3030170.png

* Disable#

../../media/3030171.png

Enable#

Brazil Bank Code#

../../media/3030510.png

* Disable#

../../media/3030511.png

Enable#

Digital Barcode#

../../media/A0.png

0#

../../media/A1.png

1#

../../media/A2.png

2#

../../media/A3.png

3#

../../media/A4.png

4#

../../media/A5.png

5#

../../media/A6.png

6#

../../media/A7.png

7#

../../media/A8.png

8#

../../media/A9.png

9#

../../media/A-.png

Cancel#

Contents
